Popular Database Partitioning Techniques

Popular Database Partitioning Techniques in 2023

Popular Database Partitioning Techniques

Why do we need to split our databases? What are the advantages of database partitioning? You will find all of your answers on this blog. But first, you should understand what partitioning is. Partitioning simply implies separating into parts or subdividing. Large database tables can be managed using partitioning strategies.

Nowadays, in this big data world, modern enterprises are dealing with critical data administration and data storage issues. Companies deal with massive terabytes of data, and the organization of their massive databases has become one of the most pressing challenges for the computer world today.

Proper strategies must be followed to come up with clever ways of sustaining such large amounts of data. Reshape your career with our Data Science Courses in Chennai with IBM Certification at Softlogic.

Introduction to Partitioning

When a large problem is divided into smaller sub-problems, it is much easier to solve. That is exactly what the partitioning strategy accomplishes. It separates a large database including data metrics and indexes into smaller and more manageable data slices. SQL queries use the partitioned tables directly, with no modifications.

Once the database has been partitioned, the data definition language may easily work on the smaller partitioned slices rather than the entire database. This is how partitioning alleviates the difficulties associated with handling huge database tables.

The partitioning key is made up of a single or extra column that is used to determine where the rows will be stored. These partition keys are used by Spark to modify the partitions.

Partitioning Key Extensions

Key extensions help with the identification of keys used in partitioning procedures. These extensions are described further below.

Reference Partitioning: Reference partitioning allows for the separation of two databases that are linked by referential constraints. It generates a new partition key from another active relationship by activating the primary and foreign keys.

Virtual Column-based Partitioning: A database can be partitioned even if the partition keys are physically unavailable. This is made possible by the virtual column-based partitioning method, which generates logical partition keys from the data table’s columns.

Popular Partitioning Techniques

Spark provides three information allocation processes, which are as follows:

These information allocation processes partition database tables in two ways: single-level partitioning and composite partitioning.

Single-story Partitioning

Any data table is addressed by selecting one of the aforementioned data distribution strategies and assigning a partitioning key to one or more columns. The techniques are as follows:

  • Hash Partitioning
  • Range Partitioning
  • List Partitioning

Hash Partitioning

Oracle has a hash algorithm that can recognize partition tables. This algorithm divides the rows uniformly into distinct divisions, resulting in partitions with identical sizes. The technique of dividing database tables into smaller parts using this hash algorithm is known as hash partitioning.

Hash partitioning is an excellent method for distributing data uniformly across multiple devices. This partitioning approach is a user-friendly partitioning mechanism, especially when the data to be detached lacks an obvious partitioning key.

Range Partitioning

Range partitioning separates information into several divisions based on the ranges of values of the specific partitioning keys for each data partition. It is a well-known partitioning strategy that is typically used with dates. For example, it will have a table with the column name ‘May’ and rows with dates ranging from May 1 to May 31 to represent the days of May.

All partitions less than a specific partition occur before the VALUES LESS THAN clause, and all partitions larger than that partition come after the VALUES LESS THAN clause. The MAXVALUE clause is used to denote the highest range partition.

List Partitioning

List partitioning allows you to publicly organize the rows that are divided into partitions by specifying a set of independent standards for the partitioning key in a separate account for each division. Even different and scrambled information tables can be managed comfortably with this partitioning strategy.

The incorporation of the probable terms into the table generated by the list partitioning method can be avoided by utilizing the default partition process to avoid problems during the partition of rows in the massive database.

Composite Partitioning

A minimum of two partitioning techniques on the data are used in the composite partitioning method. The database table will be divided using one partitioning technique at first, and then the resulting partition slices will be partitioned again using another partitioning procedure.

Types of Composite Partitioning

  • Composite Range–Range Partitioning
  • Composite Range–Hash Partitioning
  • Composite Range–List Partitioning
  • Composite List–Range Partitioning
  • Composite List–Hash Partitioning
  • Composite List–List Partitioning

Composite Range – Range Partitioning

The partition and sub-partition are done by the same range partitioning system in this composite partitioning. Because dates are commonly used in this partition, the process might be completed by partitioning with the launch date, followed by sub-partitioning with the purchasing date.

Composite Range – Hash Partitioning

This approach combines the range and hash partitioning methods. The data table is first divided using the range partitioning method, and the resulting subdivisions are further subdivided using the hash partitioning strategy. It combines the advantages of the two methods, namely the range method’s controlling power and the hash method’s information placement and striping.

Composite Range – List Partitioning

Composite range – list partitioning chops information using the range approach, and each split is further divided using the list method.

Composite List – Range Partitioning

The data is first partitioned using the list partitioning strategy in this composite division. Once the data has been organized into various partitions in the list, the range partition mode is used to subdivide all of the specified partitions.

Composite List – Hash Partitioning

This enables hash sub-partitioning of data that has already been list-partitioned. The list partition is followed by the hash partition process in this case.

Composite List – List Partitioning

This type of composite partitioning scheme uses the List partitioning scheme for both partitioning and sub-partitioning. The list method is used to divide the initial giant table, and the results are then chopped down into sub-partitions using the same list method, providing even smaller slices of data.

Advantages of Partitioning

  • It improves query functionality. Because queries can be readily and quickly solved for a collection of partitions rather than a large database. As a result, the functionality and performance levels improve.
  • The planned intermission time is shortened.
  • It speeds up information management tasks such as data loading, index creation and restoration, and backup and restores at the partition stage. Processes get faster as a result.
  • Parallel implementation provides detailed benefits for optimizing resource consumption while also shortening implementation time. In a congested environment, parallel execution next to partitioned substances is a solution for scalability.


Partitioning techniques not only improve the operation and management of very big data centers, but they also allow medium-range and smaller databases to profit from them. Although it may be implemented in all sizes of databases, it is especially useful for those that handle large amounts of data.

The scalability of partitioning strategies demonstrates that the advantages afforded to smaller data centers do not change when it comes to larger data centers. Learn more in our SQL Training in Chennai with 100 Placement Assistance and IBM Certification at Softlogic Systems.
